Product Summary

The NCP5331 is a second-generation, two-phase, buck controller that incorporates advanced control functions to power 64-bit AMD Athlon processors and low voltage, high current power supplies. Proprietary multiphase architecture guarantees balanced load-current sharing, reduces output voltage and input current ripple, decreases filter requirements and inductor values, and increases output current slew rate.

Parametrics

NCP5331 absolute maximum ratings: (1)Operating Junction Temperature: 150℃; (2)Lead Temperature Soldering; 183℃; (3)SMD Reflow Profile (60 seconds maximum): 230℃; (4)Storage Temperature Range -65 to 150℃ ; (5)Package Thermal Resistance: Junction-to-Ambient, RqJA 52℃/W ; (6)ESD Susceptibility (Human Body Model): 2.0kV.

Features

NCP5331 features: (1)Reduced SMT Package Size (7 mm × 7 mm); (2)Enhanced V2 Control Method; (3)Four On-Board Gate Drivers; (4)Internal PWM Ramps; (5)Differential Remote Voltage Sense; (6)Fast Feedback Pin (VFFB); (7)5-Bit DAC with 0.8% System Tolerance; (8)Timed Hiccup Mode Current Limit; (9)Power Good Output with Programmable Delay; (10)Advanced Overvoltage Protection (OVP); (11)Adjustable Output Voltage Positioning; (12)150 kHz to 600 kHz Operation Set by Resistor; (13)Independent Current Sense Amplifiers; (14)5.0 V, 2 mA Reference Output.

Diagrams

NCP5331 Application Diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NCP5331
NCP5331
Other

Data Sheet
Negotiable
NCP5331FTR2
NCP5331FTR2
ON Semiconductor
Switching Converters, Regulators & Controllers 2 Phase Buck w/Gate
Data Sheet
Negotiable
NCP5331FTR2G
NCP5331FTR2G
ON Semiconductor
Switching Converters, Regulators & Controllers 2 Phase Buck w/Gate Drivers for Athlon
Data Sheet
Negotiable
